Type | Rated output | Voltage | Frequency | Speed | Efficiency | Power factor | Rated Current | ILR / Irated | TLR/Trated | LWA | |
Kw | HP | V | Hz | r/min | % | cosΦ | A | Lw dB(A) | |||
80M1-2 | 0.75 | 1 | 220 | 50 | 2800 | 72.0 | 0.95 | 5 | 5.5 | 1.8 | 75 |
80M2-2 | 1.1 | 1.5 | 220 | 50 | 2800 | 74.0 | 0.95 | 7.1 | 5.5 | 1.8 | 75 |
90S-2 | 1.5 | 2 | 220 | 50 | 2840 | 75.0 | 0.95 | 9.6 | 5.5 | 1.8 | 78 |
90L-2 | 2.2 | 3 | 220 | 50 | 2840 | 76.0 | 0.95 | 13.9 | 5.5 | 1.7 | 78 |
100L-2 | 3 | 4 | 220 | 50 | 2840 | 78.0 | 0.95 | 18.4 | 6 | 1.7 | 83 |
112M-2 | 3.7 | 5 | 220 | 50 | 2840 | 79.0 | 0.95 | 22.4 | 6 | 1.7 | 83 |
132S-2 | 5.5 | 7.5 | 220 | 50 | 2880 | 80.0 | 0.95 | 32.9 | 6 | 1.7 | 83 |
80M1-4 | 0.55 | 0.75 | 220 | 50 | 1400 | 68.0 | 0.92 | 4 | 5 | 1.7 | 70 |
80M2-4 | 0.75 | 1 | 220 | 50 | 1400 | 70.0 | 0.95 | 5.1 | 5 | 1.7 | 70 |
90S-4 | 1.1 | 1.5 | 220 | 50 | 1400 | 71.0 | 0.95 | 7.4 | 5 | 1.7 | 73 |
90L-4 | 1.5 | 2 | 220 | 50 | 1400 | 73.0 | 0.95 | 9.8 | 5 | 1.7 | 73 |
100L1-4 | 2.2 | 3 | 220 | 50 | 1400 | 75.0 | 0.95 | 14 | 5 | 1.7 | 78 |
100L2-4 | 3 | 4 | 220 | 50 | 1400 | 77.0 | 0.95 | 18.6 | 5 | 1.7 | 78 |
112M-4 | 3.7 | 5 | 220 | 50 | 1430 | 78.0 | 0.95 | 22.7 | 5.5 | 1.7 | 83 |
132S-4 | 5.5 | 7.5 | 220 | 50 | 1440 | 79.0 | 0.95 | 33.3 | 5.5 | 1.7 | 83 |
